Basic Line Modules
Products
SINAMICS S120 basic line module 500-690V 3AC, 50/60 Hz, 1400A Output: 675-930 V DC Type rating: 1100kW Built-in unit IP00 design CIM Internal air cooling incl. Drive-CLiQ cable
SINAMICS S120 BASIC LINE MODULE INPUT: 3-PH 380-480V, 50/60HZ OUTPUT: 510-650 VDC, 530A, 250KW FRAME SIZE: CHASSIS WITH PLUG-IN BOARD (CIM) INTERNAL AIR COOLING INCL. DRIVE-CLIQ CABLE
SINAMICS S120 basic line module 500-690V 3AC, 50/60 Hz, 680A Output: 675-930 V DC Type rating: 560kW Built-in unit IP00 design CIM Internal air cooling incl. Drive-CLiQ cable
SINAMICS S120 basic line module 500-690V 3AC, 50/60 Hz, 1880A Output: 675-930 V DC Type rating: 1500kW Built-in unit IP00 design CIM Internal air cooling incl. DRIVE-CLiQ cable
SINAMICS S120 basic line module 500-690V 3AC, 50/60 Hz, 1100A Output: 675-930 V DC Type rating: 900kW Built-in unit IP00 design CIM Internal air cooling incl. Drive-CLiQ cable
SINAMICS S120 basic line module 380-480V 3AC, 50/60 Hz, 820A Output: 510-650 V DC Type rating: 400kW Built-in unit IP00 design CIM Internal air cooling incl. Drive-CLiQ cable
SINAMICS S120 Basic Line Module Input: 500-690V 3AC, 50/60 Hz output: 675-930 V DC, 300 A, 250 kW type of construction: built-in with withdrawable electronic unit (CIM) Internal air cooling incl. DRIVE-CLiQ cable
SINAMICS S120 basic line module 380-480V 3AC, 50/60 Hz, 1880A Output: 510-650 V DC Type rating: 900kW Built-in unit IP00 design CIM Internal air cooling incl. DRIVE-CLiQ cable
SINAMICS S120 Active Interface Module for Active Line Module 380/500 kW 380-480V 3AC, 50/60 Hz, 840 A Type rating: 500kW Built-in unit IP00 Internal air cooling incl. Drive-CLiQ cable with Pt1000
SINAMICS S120 basic line module 380-480V 3AC, 50/60 Hz, 1500A Output: 510-650 V DC Type rating: 710kW Built-in unit IP00 design CIM Internal air cooling incl. Drive-CLiQ cable
SINAMICS S120 basic line module 380-480V 3AC, 50/60 Hz, 1200A Output: 510-650 V DC Type rating: 560kW Built-in unit IP00 design CIM Internal air cooling incl. Drive-CLiQ cable
SINAMICS S120 basic line module 500-690V 3AC, 50/60 Hz, 430A Output: 675-930 V DC Type rating: 355kW Built-in unit IP00 design CIM Internal air cooling incl. Drive-CLiQ cable
