PM330 Power Modules
Products
SINAMICS G120P POWER MODULE PM330 WITHOUT FILTER WITHOUT BULT IN BRAKING CHOPPER 3AC380-480V +10/-10% 47-63HZ OUTPUT HIGH OVERLOAD: 160KW FOR 150% 60S,100% 240S OUTPUT LIGHT OVERLOAD: 200KW FOR 110% 60S, 100% 240S AMBIENT TEMP 0 TO +40 DEG C 1447 X 452 X 328 (HXWXD), FSGX PROTECTION IP20 WITHOUT CONTROL UNIT AND PANEL APPROVED with CU230P-2 FOR FIRMWARE-VERSION V4.6
SINAMICS G120P Power Module IP20 500-690V 3AC, 50/60 Hz, 368A Rated power: 315kW 6-pulse supply without power recovery Version without Control Unit
SINAMICS G120P Power Module IP20 3AC 500-690, 50/60 Hz, 725A Rated power: 630 kW 6-pulse infeed without power recovery Version without Control Unit
SINAMICS G120P Power Module IP20 500-690V 3AC, 50/60 Hz, 453A Rated power: 400kW 6-pulse supply without power recovery Version without Control Unit
SINAMICS G120P Power Module IP20 380-480V 3AC, 50/60 Hz, 655A Rated power: 355kW 6-pulse supply without power recovery Version without Control Unit
SINAMICS G120P Power Module IP20 380-480V 3AC, 50/60 Hz, 1021A Rated power: 560 kW 6-pulse infeed without power recovery Version without Control Unit
SINAMICS G120P Power Module IP20 500-690V 3AC, 50/60 Hz, 400 A Rated power: 355kW 6-pulse supply without power recovery Version without Control Unit
SINAMICS G120P POWER MODULE PM330 WITHOUT FILTER WITHOUT BULT IN BRAKING CHOPPER 3AC380-480V +10/-10% 47-63HZ OUTPUT HIGH OVERLOAD: 200KW FOR 150% 60S,100% 240S OUTPUT LIGHT OVERLOAD: 250KW FOR 110% 60S, 100% 240S AMBIENT TEMP 0 TO +40 DEG C 1447 X 452 X 328 (HXWXD), FSGX PROTECTION IP20 WITHOUT CONTROL UNIT AND PANEL APPROVED with CU230P-2 FOR FIRMWARE-VERSION V4.6
SINAMICS G120P Power Module IP20 380-480V 3AC, 50/60 Hz, 910 A Rated power: 500 kW 6-pulse infeed without power recovery Version without Control Unit
SINAMICS G120P POWER MODULE PM330 WITHOUT FILTER WITHOUT BULT IN BRAKING CHOPPER 3AC380-480V +10/-10% 47-63HZ OUTPUT HIGH OVERLOAD: 132KW FOR 150% 60S,100% 240S OUTPUT LIGHT OVERLOAD: 160KW FOR 110% 60S, 100% 240S AMBIENT TEMP 0 TO +40 DEG C 1447 X 452 X 328 (HXWXD), FSGX PROTECTION IP20 WITHOUT CONTROL UNIT AND PANEL APPROVED with CU230P-2 FOR FIRMWARE-VERSION V4.6
SINAMICS G120P Power Module IP20 380-480V 3AC, 50/60 Hz, 585A Rated power: 315kW 6-pulse supply without power recovery Version without Control Unit
SINAMICS G120P Power Module IP20 380-480V 3AC, 50/60 Hz, 840 A Rated power: 450 kW 6-pulse infeed without power recovery Version without Control Unit
SINAMICS G120P Power Module IP20 380-480V 3AC, 50/60 Hz, 735A Rated power: 400kW 6-pulse supply without power recovery Version without Control Unit
